[Function DTH 3000 - DTH 6000]
- The internal integrated ultrasonic movement
- Super fine humidification particles, fog particle diameter is only 1-5µm
- Automatic control, the current humidity display
- Automatic Water in, with overflow protection
- Integrated fog module. The chip can be changed, maintenance is simple
- Facility flexible move, install convenient
- Many install methods independently humidity (PVC pipe humidity etc)
- Independently humidity, air-flow direction can be adjusted freely
- Automatically shut-down when lack of water
- Uniformity humidification, the maximum humidity up to 99%
- High humidification efficiency, the effective humidifying up to 95%
- the bottom with caster, can move freely
| PART NO |
DTH3000 | DTH3600 |
DTH4200 |
DTH4800 |
DTH5400 | DTH6000 |
| Humidity Removal | 30KG/H | 36KG/H | 42KG/H | 48KG/H | 54KG/H | 60KG/H |
| Adjusted Range | 1~99%RH | 1~99%RH | 1~99%RH | 1~99%RH | 1~99%RH | 1~99%RH |
| Control Precision | ±3%RH | ±3%RH | ±3%RH | ±3%RH | ±3%RH | ±3%RH |
| Voltage | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Rated Power | 3000W | 3600W | 4200W | 4800W | 5400W | 6000W |
| Mist Outlet | 160mm (PVC pipe outlet for two) | |||||
| Control Model | Automatic control, humidity display | |||||
| Water Inlet Method | Automatic | |||||
| Body Protection Measures | Lack of water protection, overflow water protection | |||||
| Machine Size/Carton Size(MM) | 1000*620*630/ 1050*670*690 |
1000*910*700/ 1050*970*750 |
1100*910*700/ 1150*970*750 |
|||
| Net Weight/Gross Weight(KG) | 100/120 | 115/130 | 130/145 | 145/160 | 162/180 | 180/200 |
| Applying Area | 300~350m² | 360~400m² | 420~450m² | 480~520m² | 540~580m² | 600~650m² |
| Loading Quantity (20’/40’/40’HQ) | 53/110/138 | 33/70/88 | 30/63/80 | |||
